• Heavy-duty reel designed for longer lengths.

• Choose gear-driven crank rewind or chain and sprocket drive powered by an electric, hydraulic or compressed air motor.

• Crank rewind reels supplied with pinion brake and power rewind reels with a comet brake.

• Standard inlet 90° ball bearing swivel joint 1-1/2" female NPT threads and 2" victaulic groove.

• Standard outlet flanged riser 1-1/2" female NPT threads.

• Standard inlet, outlet riser and hub assembly are steel.

Optional bronze or aluminum swivel joint and stainless steel hub assembly and riser are available.

• Rollers may be purchased as accessory items.

• Operate at pressures to 600 psi (41 bar).

• Temperatures from -60° F to +175 F (-51° C to +79° C).

• Consult PM&I for other pressures & temps, optional chainguard.

For:

• Fuel Dispensing (Consult PM&I)

• Bulk Transfer
