Industrial Heavy Duty Hose Reel & Cable Reel

Portable Cable Reel

AV1 Audio Video Line Reel

AV1 Line Reel

AV2 Line Reel

AV3 Line Reel

Standard

With Casters

With Optional Casters

Cable and End Plate Not Included

Broadcast and pro-audio applications.

The reels are stackable and have side mounted connector panels.

Features optional heavy-duty, locking caster wheels (set includes 2 locking and 2 non-locking casters)

Rugged steel and aluminum construction throughout. Square tubing frame.

Black, non-reflective matte finish.

Removable side panel (blank panel is supplied as standard)

Standard strain relief inside panel compartment.

Frame clips allow stacking.

Optional pull handle is available for AV-2 and AV-3 (p/n 9949.0500)

Adjustable Cam-lock drag brake.
