Series SSN800 Stainless Steel Hose Reel

To Handle 3/4 or 1 Inch ID Hose

• Standard N series has a narrow frame and compact mounting base.

• Non sparking ratchet assembly.

• Declutching arbor to prevent damage from reverse winding.

• Standard inlet 90° stainless steel ball bearing swivel joint 1" female NPT threads.

• Standard outlet 1" female NPT threads.

• Pressures to 1000 psi (69 bar).

• Temperatures from +20° F to +400° F (-7° C to +204° C).

• Consult factory for other pressures & temps.

• 4-way roller assembly

• Constant Tension is available – consult factory.

• 304 stainless steel construction.

• Dairy

• Caustic Materials

• Air/Water

• Chemical/Food Transfer
