Hannay Reels

Hannay Stainless Hose Reel

Series SS1000 Stainless Steel Reel

To Handle Single 1/4 or 3/8 Inch ID Hose

Up to 3000 psi and 400 Degrees F

Manual Rewind and Compact

• Lightweight, compact

• Direct crank rewind permanently attached.

• Adjustable cam-lock brake standard.

• Optional pin lock available.

• Standard inlet 90° stainless steel ball bearing swivel joint 1/2" female NPT threads.

• Standard outlet 3/8" female NPT threads.

• Pressures to 3000 psi (207 bar).

• Temperatures from +20° F to +400° F (-7° C to +204° C).

• Consult factory for other pressures & temps.

• 304 stainless steel construction.

Applications:

• Pressure Washing

• Spray Operations

• Steam Cleaning

• Washdown

• Air

• Mobile & Permanent Installations
