PDH Series Lever Chain Hoists

Lever Chain Hoist PDH Series

.25 to 9 Metric Ton

1.5 Meter Standard Lift Customization Possible

1, 2 or 3 Chain Fall

● Made to the Standard: EN13157

● Lever hoist capacity range from 0.75 ton to 9 ton.

● Ergonomic handle design so that the hoist is easy to operate, product suitable for all application.

● Suspension and load hooks are made of alloy steel 35CrMo, heat treated and fitted

   with heavy duty safety latches, fitting groove and inspection points.

● Machined chain sprocket and gears provide smoother, more efficient operation.

● Hook with safety latch securely can rotate freely 360 degrees.

● Gears are made up of 20CrMnTi, material which ensures toughness and better strength.

● Fitted with high strength grade 80 alloy steel load chain with galvanized finish for

   corrosion  resistance. (comply with EN 818-7, safety factor 4).

● Load chain marked with T8 marks as per EN 818-7.

● Heavy duty guide rollers for avoiding slippage of load chain.

● Nylon pull ring.

● All hoists tested at 1.5 times of WLL.
