Hannay Reels

Hannay Aviation Fuel Hose Reels

To handle 1-1/4" or 1-1/2" I.D. hose.

Spring Rewind Reels

Features:

Roll formed channel frame construction.

Non sparking ratchet assembly.

Declutching arbor to prevent damage from reverse winding.

Standard inlet 90° swivel joint 1-1/2" female NPT threads and 2" victaulic groove.

Standard outlet 1-1/2" female NPT threads.

Consult factory for other sizes and/or threads.

Standard inlet, outlet riser, and hub assembly are aluminum for jet fuels.

Pressures to 600 psi (41 bar)

Temperatures from -25° F to +400° F (-32° C to +204° C).

Consult factory for other pressures & temps.

4-way roller assembly.

Constant Tension is available – consult factory.
