To handle single 3/4" or 1" I.D. hose.

• Lightweight compact reels designed for long lengths of hose in manual and power rewind.

• Gear driven crank rewind handle is removable.

• Chain and sprocket drive powered by electric, hydraulic, or compressed air motor.

• Gear driven crank rewind, adjustable pinion brake.

• Standard inlet 90° ball bearing swivel joint 1" female NPT threads.

• Standard outlet 1" male NST threads.

• Optional Rollers: Specify roller position when ordering.

• Pressures to 1000 psi (69 bar).

• Temperatures from -60° F to +250° F (-51° C to +121° C).

• Consult factory for other pressures & temps.

CAUTION: F4000/4100 series reels not recommended for use with Niedner Reeltex hose.
