Stainless Swageless Quick Attach Fittings

Stainless Swageless Stud and Toggle

316 Stainless Steel
  Stainless Swageless Stud and Toggle

Stainless Swageless Stud and Toggle

ITEM A B C D E F WT
S0764-0703 1/8" 1/4" 4.20" 7.25" 0.35" 0.23 0.25
S0764-0704 5/32" 1/4" 4.20" 7.50" 0.35" 0.23 0.27
S0764-0904 5/32" 5/16" 4.32" 8.00" 0.40" 0.30 0.44
S0764-0905 3/16" 5/16" 4.32" 8.31" 0.40" 0.30 0.50
S0764-1005 3/16" 3/8" 4.90" 9.25" 0.56" 0.37 0.64
S0764-1007 1/4" 3/8" 4.90" 9.75" 0.56" 0.37 0.74
S0764-1307 1/4" 1/2" 5.87" 11.00" 0.63" 0.47 1.30
S0764-1309 5/16" 1/2" 5.87" 12.25" 0.63" 0.47 1.54
S0764-1609 5/16" 5/8" 7.50" 15.00" 0.80" 0.62 2.75
S0764-1610 3/8" 5/8" 7.50" 15.75" 0.80" 0.62 2.95
