PBGMT and PBGMB Series LP Gas Hose Reel

For 1" through 1 1/2" ID Hose

Power Rewind Reels

With Top or Bottom Mounted Guide

POWER REWIND REELS

To handle single 1" or 1-1/2" I.D. hose.

Both Series:

• Choose #40 chain and sprocket drive powered by an electric,

hydraulic or compressed air motor or direct drive hydraulic rewind motor.

• Auxiliary crank rewind standard on DPB Series reels. Available on

PB Series power rewind reels, at extra cost.

• Direct drive hydraulic rewind reels supplied with pinion brake.

Electric powered rewind reels supplied with a strap brake.

• Other brake and locking devices may be specified. (See Ordering & Accessory Guide)

• Standard inlet is 90° ball bearing swivel joint with 1-1/2" female NPT threads.

• Standard outlet is a flanged riser with 1" female NPT threads.

• Standard inlet, outlet riser, hub assembly are steel.

• Other sizes and/or threads can be furnished and must be specified.

• Pressures to 350 psi (24 bar).

• Temperatures from -40° F to +350° F (-40° C to +177° C).

• Consult factory for other pressures and temps.

• Chain guard available upon request, must be specified.

Series PBGMB:

• For PBGMB reels the assembly B bottom wind roller is standard.
