PB and DPB Series LP Gas Hose Reel

For 1" through 1 1/2" ID Hose

Manual or Power Rewind

MANUAL OR POWER REWIND REELS

To handle single 1" through 1-1/2" I.D. hose.

• Series PB are explosion-proof reels.

• New DPB Series reel is direct drive eliminating the use of chain and sprockets.

• Choose gear-driven crank rewind, #40 chain and sprocket drive powered by an electric, hydraulic or compressed air motor or

direct drive hydraulic rewind motor.

• Crank rewind reels and direct drive reels supplied with pinion brake.

• Power rewind reels (chain & sprocket driven) supplied with a strap brake. Other brake and locking devices may be specified.

• Standard inlet is 90° ball bearing swivel joint with 1-1/2" female NPT threads.

• Standard outlet is a flanged riser with 1" female NPT threads.

Standard inlet, outlet riser, and hub assembly are steel.

• Other sizes and/or threads can be furnished and must be specified.

• Rollers and roller mounting brackets are accessory items. Specify roller position.

• Pressures to 350 psi (24 bar).

• Temperatures from -40° F to +350° F (-40° C to +177° C).

• Consult factory for other pressures and temperatures.

• Chainguard available upon request, must be specified.
