Basket Strainer

Fabricated

FB3 Series

Pressure Drop vs. Flow Rate Open Area Ratios Pressure vs. Temp Chart

Standard cover is bolted
Cover lifting lug standard on 10" sizes and larger.
Class 150# and 300# flanges are standard.
Class 600# and higher available upon request.
Various screen openings available.

FB3 Fabricated Basket Simplex Strainer

FB3 Fabricated Basket Simplex Strainer
