Turbidity Curtain

Height (mm)

600

750

800

900

1000

1100

Freeboard (mm)

180

260

250

330

325

320

Draft (mm)

320

400

410

540

650

770

Section Lengths (M)

20,15,10

20,15,10

20,15,10

20,15,10

20,15,10

20,15,10

Turbidity Curtain Depth

Various

Various

Varous

Various

Various

Various

Tension Strength (KN)

20

40

55

65

80

120

Float Weight

3.9

5.6

4.9

6.2

5.6

5.5

Weight(Kg/Meter)

3.7

6.2

7.1

8.4

9.3

9.5

Wave Height (M)

.5

1

1.5

1.8

2

2

Wind Speed (M/S)

10

15

15

18

18

20

Current Speed (KN)

1

1.5

2

2

2.5

2.5
