PDLER Single Girder Electric Wire Rope Hoist

3.2 to 20 Metric Tons Capacity

6 to 18 Meters Standard Lift

3.2 to 20 Metric Tons Capacity

Up to 18 Meter Lifts

● Trolley with frequency conversion motor.
● Double speed/frequency conversion lifting motor.
● Motor protection grade IP55, insulation grade F.
● Electromagnetic maintenance free disc brake.
● Control voltage 24V/36V/48V/110V.
● Schneider contactor & inverter.
● Phase, Voltage and Hz as required.
● Lifting limit switch.
● Hook, with safety latch.
● Overload limiter.
● Ambient temperature: -20°C~+40°C.
● Motor over temperature protection.
