18 Inch Marine Mooring Cleat 2 Bolt Steel Rated for Load Capacity: Model PC2-18
$200.00
100 in stock
18 Inch 2 Bolt Steel Marine Mooring Cleat
15 to 38 Metric Ton Breaking Load Depending on Bolts Used
2 Bolt Steel Cleat with Zinc Rich Primer
Designed for 7/8 Inch Diameter Heavy Hex Head Bolts and Heavy Hex Head Socket
| 18 Inch Cleat: | Breaking Load** | Breaking Load** |
| Bolt | Pounds (Shear) | Metric Tons (Shear) |
| Grade 8: 7/8-9 Coarse Bolt | 83,160 lbs. | 37.8 mt |
| Grade 5: 7/8-9 Coarse Bolt | 66,528 lbs. | 20.24 mt |
| Grade 1: 7/8-9 Coarse Bolt | 33,264 lbs. | 15.2 mt |
** Theoretical Breaking Load
See PM&I's Complete Bollard and Cleat Catalog Here
We Carry Up to 300 Ton Bollards and 57 Inch Cleats
Additional information
| Weight | 45 lbs |
|---|---|
| Dimensions | 18 × 4 × 5 in |
