Marine Hydraulic Capstan

Right Angle Open

Specification
Marine Hydraulic Capstan


Information Needed for Marine Capstan Quotations

Model Number VC -HYD
2000-26 		VC -HYD
5000-30 		VC -HYD
5000-45 		VC -HYD
8000-13 		VC-HYD
8000-30		 VC-HYD
12000-17		 VC-HYD
15000-13		 VC-HYD
18000-17 		VC-HYD
22000-17
Working Load Limit
Starting		 lb 2000 5000 5000 8000 8000 12000 15000 18000 22000
kg 907 2268 2268 3628 3628 5442 6803 8163 9977
Working Load Limit
Running		 lb 1000 2500 2500 4000 4000 6000 7500 9000 11000
kg 454 1134 1134 1814 1814 2721 3401 4082 4989
Rope Speed ft/min 26 30 45 13 30 17 13 17 17
m/min 8 9 14 4 9 5 4 5 5
Rope Diameter*
(Polypropylene)		 in 5/8 1-1/8 1-1/8 1-1/2 1-1/2 1-3/4 2 - -
mm 16 29 29 38 38 44 50 - -
Rope Diameter*
(Spect-Set)		 in 5/8 5/8 5/8 3/4 3/4 7/8 1 1-1/4 1-1/4
mm 16 16 16 20 20 22 25 32 32
Weight lb 202 330 355 452 474 660 1124 1162 1379
kg 92 150 161 205 215 299 510 527 625

Marine Hydraulic Capstan
