Manual or Power Rewind Reels

To handle single 1/4" through 5/8" I.D. hose.

• Lightweight compact reels designed for long lengths of hose in manual and power rewind.

• Direct crank rewind is permanently attached.

• Chain and sprocket drive powered by electric, hydraulic, or compressed air motor.

• Direct crank rewind, cam-lock drag brake, spring actuated pin lock• Optional Rollers: Specify roller position when ordering.

• Standard inlet 90° ball bearing swivel joint 1/2" female NPT threads.

• Standard outlet 1/2" female NPT threads.

• Pressures to 3000 psi (207 bar)

• Temperatures from +20° F to +400° F (-7° C to +204° C).

• Consult factory for other pressures & temps.

• Optional hose guide available, see page 14.

For:

• Lawn Care

• Pest Control

• Pressure Washing

• Agriculture

• Steam Cleaning
