LED Sector Light MEL 200L

LED Sector Light MEL 200L



The MEL 200L is a sector leading light, whose light source is made of high-intensity LED technology.
Designed for port accessing channels during day and night as a single and complete leading station.



Configured individually by units, each element produce one sector of a different color.
The union of the elements in a special support allows to obtain the desired sectors configuration.



Light emission generates a highly defined sectorised unidirectional beam

with a horizontal divergence maximum of 5º for each element.



Light beam colour sector configuration is expressly done for every case, and always

according to IALA Recommendations and Guidelines



LED Sector Light MEL 200L

LED Sector Light MEL 200L
